Model Number : LFXP2-5E-5FTN256
Certification : ROHS
MOQ : 1pcs
Price : Negotiated
Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability : 1000pcs
Delivery Time : 3-15days
Packaging Details : Tray/REEL
Stock : 8000
Manufacturer Product Number : LFXP2-5E-5FTN256
Logic Cells : 160 Kbits
Phase Locked Loops (PLLs) : 12
Maximum Operating Frequency : 500 MHz
I/O Standards : LVDS, SSTL, HSTL
Package : 256-pin Fine-Pitch Thin Quad Flatpack
LFXP2-5E-5FTN256 FPGA Chip: Applications, Features, and Product Attributes
Find information here in stock.xlsx
Applications:
The LFXP2-5E-5FTN256 is a Field-Programmable Gate Array (FPGA) chip that is designed for high-performance applications. It is used in various industries, including communications, industrial automation, aerospace, and defense.
Introduction:
The LFXP2-5E-5FTN256 is a member of the LatticeXP2 family of FPGA chips. It contains 5,120 Look-Up Tables (LUTs), 160 Kbits of embedded block RAM, and 12 Phase Locked Loops (PLLs). The chip has a maximum operating frequency of 500 MHz and supports various I/O standards, including LVDS, SSTL, and HSTL. The LFXP2-5E-5FTN256 is designed for low power consumption and has a standby current of less than 12 mA.
Product Attributes:
Product Attribute | Value |
---|---|
Logic Cells | 5,120 |
Embedded Block RAM | 160 Kbits |
Phase Locked Loops (PLLs) | 12 |
Maximum Operating Frequency | 500 MHz |
I/O Standards | LVDS, SSTL, HSTL |
Package | 256-pin Fine-Pitch Thin Quad Flatpack |
Voltage | 1.2 V |
Power Consumption (Standby) | <12 mA |
Power Consumption (Active) | 0.6 W (typical) |
Configuration Memory | On-chip Flash |
Product Comparison:
